TB219 FULLY HYDRAULIC COMPACT EXCAVATOR
Takeuchi’s TB219 compact mini excavator is designed for excavating in the most narrow site applications and for digging deep ideal for gravedigging. Performance is enhanced with a long dipper arm designed for maximum digging depth to 2520. The TB219 is ideal for: grave diggers, groundworks or deep utilities. With an operating weight of 1890/2000kg (canopy) the TB219 is comfortably within trailer towing limits.

1890 kg (canopy) operating weight
2520 mm dig depth
4280mm ground reach
11.5 kW / 2500 rpm engine
Two-speed travel
Hydraulic track width adjuster
Servo controls

Hydraulically adjustable tracks provide a wider and stable dig platform, with a dig depth to 2520mm, adjustable from the canopy. The unique track extension and longer dozer blade adds significant stability when excavating deep. The TB219 slims down to just 980mm (1030mm canopy), to get into the narrowest working areas including graveyard cemetery areas.

Expanding tracks for greater stability from 980mm to 1370mm.
Adjustable dozer blade width to match expanded tracks.
Balance and stability are further enhanced with a longer than average track frame (1570mm).
